How to choose the right laser line generator for your job?
In a large variety of industrial and high-tech precise line measuring work fields, it is always a hard job for users to choose the right laser line generator. According to the exact analysis below, users can choose the correct one after following the steps listed.
What is a Powell lens laser line generator?
What is a Powell lens laser line generator?
Powell lens laser line generator project high collimation laser light in one dimension. The special shape of prism with a rounded room is applied to transfer a narrow width laser beam into a highly uniform distribution illuminating vertical or horizontal laser line in use. It projects high uniformity and high straightness reference line, which keeps work with the same line brightness via middle part towards both ends, without laser brightness fade edges.
How is a laser line generated?
A typical laser device is projecting simple laser dot of laser beam aperture. A laser line is a different device that employs qualified glass coated lens or separate crystal lens(Powell Lens) with different fan angles. It is projecting special laser beam in type of a highly straight laser line, rather than a laser dot or point. Intense laser beam passing through a certain fan angle optic lens achieves a high linear quality and high fineness line in use.
What is a laser module used for?
Laser module is consisting of laser diode, optic lens, electric driving circuit board inside its durable metal housing tube. On consideration of its good thermal emitting system and electric power source supply, it is able to work with high intensity visible laser light or invisible infrared laser light source emission from laser beam aperture. Available with multiple laser module shapes, such as dot, line, cross line laser modules, fiber coupled laser modules and single mode laser diode modules etc, it is providing excellent laser source for industrial and high tech used fields.
Laser Line Generator Glass Coated Lens
In occasion that users are looking for a moderate accuracy and fineness line aligning solution, it is just the correct choice to choose laser line generator with glass coated lens. It is emitting Gaussian beam from a cylinder lens, and high linear quality laser line onto various working surface. When laser line module gets correct optic lens degree and proper mounting onto other industrial machine or device, it just makes easy and highly clear line alignment onto various working surfaces.
How to Project a Laser Line
How to project a laser line? Laser tech engineer has just focused on development of the most practically used laser device, such as a laser line generator module device. After perfect inner equipment with high quality glass cylindrical lens or Powell lens, laser line module projects a super straight and fine reference line in distance. Under selection of correct output power and lens degree, laser line projects the most precise line instruction for multiple application fields effectively.
