High Power 808nm 500mW-1000mW Infrared Laser Diode Module
Direct diode emission high power 808nm infrared laser diode module keeps the most intense IR infrared laser beam emission from high power 808nm infrared laser diode within high power range of 500mW to 1000mW. This high power IR laser device gets excellent equipment with qualified glass coated lens, APC, ACC driving circuit board and separate thermal emitting system, fulfilling the most stable and reliable IR laser source generation and the clearest IR dot measuring solution for prominent college or university, lab and institutes etc.
- Buy 3 for $314.99 each and save 1%
- Buy 5 for $312.99 each and save 1%
- Buy 10 for $310.99 each and save 2%
Under operation of night vision illuminated device, such as CCD camera, black and white camera or infrared laser camera, high power 808nm 500mW to 1000mW infrared laser diode module would be workable with super clear and accurate IR laser dot alignment efficiently. Integrated with import 808nm infrared laser diode tech and metal housing design, this high intensity beam IR infrared laser module obtains improving laser beam stability, and fulfills the highest level of accuracy IR dot generation for multiple working occasions.
◆ Wide range output power ensures the clearest IR dot alignment in distance.
Selected from 500mW, 600mW, 700mW, 800mW, 900mW and 1000mW, high power 808nm infrared laser module keeps up to 80% photoelectric ability and super clear IR infrared laser dot projection for multiple application fields, including OEM infrared laser instruments, scientific research, communication, spectrum analysis, laser medical therapy, night vision IR illuminator, and IR laser positioning devices etc.
◆ Adjustable focus ensures the highest level of accuracy dot alignment easily.
High power 808nm IR infrared laser diode module generates the most intense and powerful infrared laser beam from laser beam aperture. Easy adjustment of laser beam aperture makes sure of immediate concentration of IR laser light, forming into the most compact size infrared laser dot generation in distance immediately.
◆ High duration structure gets high stability dot alignment in harsh occasion.
Being made with aircraft used aluminum alloy housing material and copper made 808nm IR laser diode core part, the genuine IR dot alignment with high power 808nm infrared laser module guarantees superior thermal conductivity, and super stable performance under wide range environmental temperature. IR laser dot alignment keeps high stability under mechanical shocking, calibration or moving in use.
◆ APC, ACC driving circuit ensures constantly dot alignment efficiently.
Tube temperature of high power 808nm infrared laser module increases seriously after easy connect with DC input power supply. APC, ACC driving circuit board assures efficient preventing of serious electric current impacting, ensuring constant and high stability IR laser dot projection within 8 to 10 hours per day.
Key features:
◆ DC input power supply accepts wide range electric current within 100V to 240V, making sure of convenient and quick IR dot generation under strong interference or strong static etc.
◆ Reduced possibility of laser diode and electric driving circuit burning out or damage under operation by professional night vision illuminated device or equipment.
◆ Aircraft aluminum alloy made high power 808nm infrared laser module gets featured advantages of easy installation, low time consumption, and reduced relying on manual labor force input and skills.
◆ CW modulation
Technical parameters:
| Item | High Power Infrared Laser Diode Module |
| Wavelength(nm) | 808nm |
| Output power(mW) | 500mW, 600mW, 700mW, 800mW, 900mW, 1000mW |
| Beam diameter at aperture(mm) | 2mm×6mm@2M |
| Beam divergence(mrad) | 6 mrad |
| Beam mode | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝9V |
| Operating current(mA) | I<1000mA |
| Operating temperature(℃) | 10℃～30℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | Dia26mm×Length150mm |
| Expected lifetime (hours) | ≥8000 hours |
| Warranty | 6 months |
Note:
High beam intensity 808nm 500mW-1000mW infrared laser diode module keeps generation of the most intense and powerful IR infrared laser radiation and laser reflection. It only allows operation by skilled users or professionals under professional alignment equipment or device.
Any eye exposure to powerful 808nm IR laser light cause serious hurt or damage to human eyes and skins. Avoid operation without laser safety measure. Do remember to wear 808nm infrared laser safety goggles for the use of any high power 808nm IR laser device.
Power Supply:
Input: AC 100-240V, 1.0A , 50/60Hz
Output: DC 9V ,1000mA
Dimension: 70mm×46mm×27mm
Length of AC input line: 116cm
Length of DC output line: 126cm
Packing List:
1. High Power 808nm Infrared Laser Diode Module
2. DC input power Supply
Attention: For high powered or OEM 808nm infrared laser diode modules, please contact us free at support@berlinlasers.com.
