High Power 405nm Violet Line Laser Alignment

Employed by import 405nm violet laser diode, qualified optic lens degree and metal heat sink cooling system, high power 405nm violet line laser alignment is easily obtaining stable and reliable violet reference line source in use. This 405nm violet laser module gets featured advantages of compact structure, high linear quality and high speed line alignment. Correct selection of output power and optic lens degree has just provided users the most competitive line measuring solution for formal industrial line aligning and high tech use etc.

was $325.99 Special Price $289.98
Availability: In stock
SKU
HP405-line
  • Buy 2 for $287.89 each and save 1%
  • Buy 5 for $285.89 each and save 1%
  • Buy 10 for $283.89 each and save 2%

As a professional line alignment device, high power 405nm violet line laser alignment is designed with a bit longer wavelength than UV lasers, which is making sure of special violet laser line aligning for fluorescence sensing, spectroscopy, biomedical instruction and imaging system etc. 405nm violet laser module gets nice thermal emitting from metal heat sink cooling system and metal housing, and intelligent feedback control of output power and electric current, assuring high stability violet laser line source for those of prominent university, lab, and institute etc.

● DC input power supply provides constant electric power source for multiple working environments.

High power 405nm violet line laser alignment adopts 8.4V DC input power supply, obtaining continuous and high stability blue reference line targeting within 8 to 10 hours per day. Blue line targeting is not affected by harsh occasion of strong inference or strong static etc.

● High performance APC driving circuit board makes excellent control of power and electric current in long term use.

High power 405nm violet line laser module gets wide range output power from 150mW to 500mW, laser tube temperature increases immediately during continuous line alignment work. APC, ACC driving circuit makes sure of intelligent feedback control of provided output power and electric current, enables up to 80% beam stability in long term line aligning use.

● Compact structure made violet laser alignment with nice thermal conductivity.

Besides good thermal emitting system of metal heat sink cooling system, 405nm violet line laser alignment is manufactured with aluminum alloy housing and copper raw material made 405nm violet laser diode core part, getting the most efficient thermal conductivity, avoiding internal part of laser diode and electric driving circuit board burning out or damage.

● Selectable output power and optic lens degree assures multiple line alignment use.

Whether glass coated lens or separate crystal lens being equipped, high power violet line laser alignment generates high intensity violet laser source, converting into 0.6 meter to 6 meters length made violet reference line in distance. Available with high power of 150mW, 200mW, 300mW, 400mW and 500mW, 405nm violet laser module assures multiple violet line alignment use for various industrial line marking, military equipment and instruments, education and experiment line source, laser medical equipment, stage lighting and demonstration laser light source etc.

Technical Data:

Item High Power Blue Violet Line Laser Alignment
Wavelength (nm) 405nm
Output power (mW) 150mW, 200mW, 300mW, 400mW, 500mW
Available Fan Angle(degrees) 10°-110°
Laser Class IIIB
Beam thickness at aperture (mm) ≤2mm; At 2m distance: ≤2mm
Beam divergence (mrad) ≤2mrad
Beam mode (before optics) TE00
Focus adjustable? No
Operating voltage(v)  DC=8.4V
Operating current (mA)  I<3000mA
Operating temperature(℃) 10℃~30℃
Storage temperature(℃) -10℃~50℃
Dimension  D26mm×L171mm
Expected lifetime (hours) 8000 hours
Warranty Period 180 days

Note:

High power violet line laser alignment only allows operation by trained people or skilled users. Users should adjust laser alignment to the best condition and operate under special alignment equipment.

Warning! 405nm high power violet laser module emits radiation and reflection that can be harmful to human eyes. Never look directly into laser beam aperture to avoid eye damage or hurt. Do remember to wear laser safety goggles for line alignment use.

Power Supply:

Input: AC 100-240V, 1.0A , 50/60Hz
Output: DC 8.4V ,3000mA
Dimension: 70mm×46mm×27mm
Length of AC input line: 116cm
Length of DC output line: 126cm

Packing List:
1.High Power 405nm Violet Line Laser Alignment
2. DC input power Supply

Attention: For high powered or OEM alignment lasers, please contact us free at support@berlinlasers.com.
