Adjusted Fineness 648nm 5mW to 100mW Red Line Laser Modules
Being made with import 648nm red laser diode, qualified optic lens and electric driving circuit board, industrial stabilized 648nm red line laser module assures highly intense red laser light emission, and highly stable and clear red line emission. Connecting with electric power source and adjusting laser beam focus, it gets increasing accuracy and fineness red line alignment for both industrial and high tech fields.
- Buy 3 for $77.99 each and save 3%
- Buy 5 for $75.99 each and save 5%
- Buy 10 for $73.99 each and save 8%
Direct diode emission 648nm red line laser modules assure low price, high stability and long lasting red line alignment. Available with wide fan angles 10 to 110 degree glass coated lens or Powell lens, after up to 24 hours beam stability tests and special use of glass window, it keeps work with high quality red laser light source, and high linear quality and fineness red line emission, no affect by moisture or dust.
Key features:
Import 648nm 5mW to 100mW red laser diodes with metal heat sink cooling system assures 40% improvement of laser beam stability, and highly clear red line measurement within maximum work distance of 25 meters and formal lighting.
5V, 9V 1000mA AC/DC adapter supports constant red laser beam emission, stable red line projection under overheating and over current impact.
Adjustable focus optic lens enables high concentration red laser light emission, and increasing brightness and accuracy red line alignment.
16mm or 26mm diameter anodized aluminum alloy housing tube assures convenient installation, easy and quick response red line projection.
APC, ACC driving circuit board assures constant output power and electric current supply. The genuine red laser line alignment assures high stability line measurement and no tube burning out or damage in continuous use.
CW or pulsing laser selectable
Technical data:
| Item | Red Line Laser Modules |
| Wavelength (nm) | 648nm |
| Output power (mW) | 5mW, 10mW, 20mW, 30mW, 50mW, 80mW, 100mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIa, IIIB |
| Beam thickness at aperture (mm) | <2mm; At 2m distance: <2mm |
| Beam divergence (mrad) | 5mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 648nm red line laser module and 1 ea AC/DC adapter
Applications: sand milling, lumber machine, industrial precise line alignment, scientific experiment and high tech
Note: For operation with high power 648nm red line laser module up to 50mW to 100mW, it projects powerful red laser radiation and reflection. Please avoid eye exposure to beam aperture and wear correct laser safety goggles so as to get safe and free line alignment constantly.
