Adjustable Focus Lens 1310nm 5mW Infrared Cross Line Laser Module

Long wavelength 1310nm 5mW infrared cross line laser module generate invisible infrared laser beam directly of far infrared laser diode. Designed with qualified glass coated lens, electric driving circuit board and AC/DC adapter, it keeps optical intensity infrared laser light emission for night version cross line measurement use. After professional use of night version device, it converts invisible infrared laser light into high precision infrared cross line source in distance clearly.

was $399.99 Special Price $349.99
Availability: In stock
SKU
1310nm-ICLLM
  • Buy 3 for $347.99 each and save 1%
  • Buy 5 for $345.99 each and save 1%
  • Buy 10 for $342.99 each and save 2%

Direct diode emission 1310nm 5mW infrared cross line laser module gets featured advantages of ultra compact design, high beam stability, good collimation and low production cost. Durable anodized aluminum alloy housing tube cooperates with qualified glass coated lens and front part glass window, assures reliable infrared cross line projection within wide operating temperature and multiple night version fields.

Key features:
Import 1310nm infrared laser diode with metal heat sink and APC, ACC driving circuit gets excellent thermal stabilization, good stability and no decay light infrared cross line projection.
AC/DC adapter makes constant infrared laser beam and infrared cross line projection, no tube temperature increasing and no electric current impact.
Qualified glass coated lens with 10, 15 and 110 degree optic lens projects different dimension and high straightness infrared cross line projection.
Adjustable focus lens gets immediate infrared laser light concentration, and increasing fineness infrared cross line measurement in use.
CW or pulsing laser selectable
Technical data:

Item Infrared Cross Line Laser Modules
Wavelength(nm) 1310nm
Output power(mW) 5mW
Available Fan Angel (degrees) 10°,15°,110°
Beam diameter at aperture(mm) <2.5mm
Beam divergence(mrad) 6 mrad
Beam mode TE
Focus adjustable? Yes
Operating voltage(v)  DC=5V
Operating current (mA)  I<1000mA
Operating temperature(℃) 10℃~45℃
Storage temperature(℃) -10℃~50℃
Dimension  D16mm×L71mm
Expected lifetime (hours) ≥8,000 hours
Warranty 6 months

Packing list: 1 ea 1310nm infrared cross line laser module and 1 ea AC/DC adapter
Applications: laser medical surgery device, infrared laser collimation, scientific research and optical instrument, infrared laser sensor etc
