Adjustable Focus 5mW to 100mW 655nm Red Laser Line Generators
Employed by import 655nm red laser diode, qualified glass coated lens or Powell lens, and APC, ACC driving circuit board, 655nm red laser line generator gets strong industrial stabilization, good thermal emitting, and high stable red line projection. Available with wide range output power of 5mW to 100mW, after easy use of AC/DC adapter, 655nm red laser module projects constant red laser light and red line alignment for labs, institutes and colleges.
- Buy 3 for $99.99 each and save 2%
- Buy 5 for $97.99 each and save 4%
- Buy 10 for $95.99 each and save 6%
The genuine design of 655nm red laser line generators apply the best quality glass coated lens or Powell lens within 10 to 110 degree. After strict laser beam stability and aging preventing tests up to 24 hours and special use of glass window in front of beam aperture, it achieves excellent laser light cycling use, and highly reliable red laser line projection under moisture or dust.
Key features:
Import 655nm red laser diode within 5mW to 100mW made red laser modules with metal heat sink cooling system assures 40% improvement of laser beam stability, and highly clear red line projection.
AC/DC adapter leaves larger space for tube cooling down, projects constant red laser beam and red reference line. No effect of increasing temperature and electric current impact.
Adjustable focus optic lens enables the best quality red laser light source emission, and increasing fineness and accuracy line alignment in use.
Wide fan angles of 10 to 110°glass coated lens or Powell lens projects various line lengths and finenesses, fulfilling high level of accuracy red line alignment within maximum distance of 25 meters and formal lighting.
CW or pulsing laser selectable
Technical data:
| Item | Red Laser Line Generators |
| Wavelength (nm) | 655nm |
| Output power (mW) | 5mW, 10mW, 20mW, 30mW, 50mW, 80mW, 100mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIa, IIIB |
| Beam thickness at aperture (mm) | <2mm; At 2m distance: <2mm |
| Beam divergence (mrad) | 5mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 655nm red laser line generator and 1 ea AC/DC adapter
Applications: industrial line alignment, laser collimation, optical instrument, scientific experiment, laser medical therapy device
Note: For operation of high power 655nm red line laser up to 50mW to 100mW, it generates powerful red laser radiation and thermal energy. Please take laser safety measure and wear correct laser safety goggles so as to achieve safe and fine line alignment constantly.
