930nm 100mW to 500mW Infrared Cross Line Laser Modules
Invisible beam emitting 930nm infrared cross line laser modules apply import 930nm infrared laser diode, qualified glass coated lens and APC, ACC driving circuit board, generate high photoelectric ability infrared laser light directly of beam aperture. Equipping with night version device and electric powers source, it assures high efficiency conversion of highly clear and fine infrared cross line source generation for all night version application fields.
- Buy 3 for $157.99 each and save 1%
- Buy 5 for $155.99 each and save 3%
- Buy 10 for $153.99 each and save 4%
Direct diode emission 930nm infrared cross line laser modules are featured by ultra compact structure, good direction, quick response and long operating lifetime. Being made with qualified glass coated lens with special designed glass window, after up to 24 hours aging preventing test, the genuine infrared cross line alignment keeps good stability and high accuracy for night version cross line measuring fields.
Key features:
Import 930nm infrared laser diode within 5mW to 500mW with metal heat sink and APC, ACC driving circuit board assures good thermal emitting, increasing stability and long lasting cross line measurement.
5V, 9V 1000mA AC/DC adapter supported 930nm infrared lasers with constant infrared laser beam and infrared cross line projection, no effect of overheating and over current impact.
Adjustable focus optic lens enables high concentration infrared laser light emission, and increasing fineness infrared cross line alignment in distance.
10, 15, 110 degree glass coated lens enables different dimension and high linear quality infrared cross line projection, applicable for multiple night version precise cross line alignments.
CW or pulsing laser selectable
Technical data:
| Item | Infrared Cross Line Laser Modules |
| Wavelength(nm) | 930nm |
| Output power(mW) | 100mW 200mW 300mW 400mW 500mW |
| Available Fan Angel (degrees) | 10°,15°,110° |
| Beam diameter at aperture(mm) | <2.5mm |
| Beam divergence(mrad) | 6 mrad |
| Beam mode | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L71mm; D26mm×L150mm |
| Expected lifetime (hours) | ≥8,000 hours |
| Warranty | 6 months |
Packing list: 1 ea 930nm infrared cross line laser module and 1ea AC/DC adapter
Applications: infrared cross line measurement, spectrum analysis, scientific research, lab experiment, infrared laser communications
Note: Long wavelength 930nm infrared lasers project invisible infrared laser radiation and reflection, and thermal energy hurt to human eyes or retina. Please wear correct laser safety goggles and avoid eye exposure to beam aperture so as to make free and secured measurement constantly.
