808nm Infrared Laser Diode Module
Diode 808nm infrared laser module integrates ultra fine laser diode, optic lens, constant current driving circuit into the most durable and compact aluminum housing. This IR laser diode module is providing the excellent IR laser beam for a wide range of applications in OEM laser instruments, scientific research, measurement, communication, spectrum analysis, medical therapy, night vision IR illuminator, and laser IR laser positioning devices etc.
- Buy 2 for $96.29 each and save 3%
- Buy 5 for $93.99 each and save 5%
- Buy 10 for $90.23 each and save 9%
Compact designed 808nm infrared laser diode module manufactured by Berlinlasers gathers high tech applied laser diode with qualified collimating lens. It fulfils various kinds of IR laser source supply requirement with features of high stability, high efficiency and high compatibility.
Ultra compact dimension allows easy integration. 808nm infrared laser modules adopts optimized compact with self-contained 808nm IR laser diode, collimating lens, driving circuit board and aircraft used aluminum housing. It allows easy integration on required devices, easy installation and easy operation.
Constant power driving realizes stable power emission. 808nm diode laser modules utilizes constant current driving circuit board, thus it provides constant stable output power IR laser emission over time and temperature. Low power required IR laser module generators low heat, low energy consumption, gets long serving lifetime of up 8000 hours.
Superior Features:
◆ Ultra Compact design of 16mm and 26mm diameters selectable
◆ Wide Output power level of 5mW ~ 500mW
◆ High reliability, high stability. IR laser Power stability is better than 5% over 8 hours continuous positioning
◆ Aircraft used aluminum housing with anodized treatment, durable, thermal conductive, projection from shocking, calibration
◆ Constant power driving circuit
◆ Focus adjustable lens
◆ CW modulation
Technical Data:
| Item | Infrared Laser Diode Module |
| Wavelength (nm) | 808nm |
| Output power (mW) | 100mW, 200mW, 300mW, 400mW |
| Laser Class | IIIb |
| Beam divergence (mrad) | 6mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| TTL Modulation | NO |
| Operating voltage(v) | DC＝3.0V |
| Operating current (mA) | I<500mA; |
| Operating temperature(℃) | 10℃～30℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L71mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Power Supply:
Input: AC 100-240V, 1.0A , 50/60Hz
Output: DC 3V ,500mA
Dimension: 70mm×46mm×27mm
Length of AC input line: 116cm
Length of DC output line: 126cm
Packing List:
1. Infrared laser diode module
2. DC input power Supply optional
WARNING! 808nm infrared laser module emits invisible IR laser radiations. It is harmful to human eyes. Laser safety goggles is necessity while IR laser is in use. Do be cautious!
Attention: For high powered or OEM 808nm infrared laser diode module, please contact us free at support@berlinlasers.com.
