795nm 5mW to 100mW Infrared Laser Line Generators
Invisible infrared laser beam emitting 795nm infrared laser line generators enables easy and convenient IR line alignment after proper use of external electric power source and night version device. It makes advanced use of qualified glass coated lens or Powell lens with wide fan angles, passing through 24 hours aging preventing and beam stability tests, 795nm infrared laser modules keep work with high stability and low production cost infrared line alignment for nigh version illumination fields.
- Buy 3 for $107.99 each and save 2%
- Buy 5 for $105.99 each and save 4%
- Buy 10 for $103.99 each and save 5%
Employed by import 795nm infrared laser diode, qualified optic lens, metal heat sink inside ultra compact anodized aluminum alloy housing tube, 795nm infrared laser line generator projects highly stable infrared laser beam and infrared line for both long distance and long lasting use. After advanced use of focus adjustable lens and external electric power source, 795nm infrared laser module keeps work with constant infrared line generation for all night version precise line measurements.
Key features:
Direct diode emission 795nm 5mW to 100mW infrared laser module with metal heat sink cooling system achieves 40% improvement of laser beam stability, and highly clear infrared line alignment in use.
5V, 9V 1000mA AC/DC adapter enables continuous infrared laser beam emission, and constant infrared line generation under increasing temperature and serious electric current impact.
Glass coated lens or Powell lens within 10 to 110 degree projects intense and high photoelectric ability infrared laser light emission, and high linear quality infrared line alignment with various line lengths.
Adjustable focus optic lens made 795nm infrared line laser module enables quick infrared laser light concentration, and efficient conversion of highly fine and straight IR line alignment in distance.
CW or pulsing laser selectable
Technical data:
| Item | Infrared Laser Line Generators |
| Wavelength (nm) | 795nm |
| Output power (mW) | 5mW, 10mW, 20mW, 30mW, 50mW, 80mW, 100mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIa, IIIB |
| Beam thickness at aperture (mm) | 10cm distance:<2.5mm |
| Beam divergence (mrad) | 6mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 795nm infrared laser line generator and 1 ea AC/DC adapter
Applications: night version infrared line alignment, surveillance, DNA sequencing, biomedical, measurement, spectrum analysis and scientific experiment etc
Note: For operation of invisible beam 795nm infrared laser, human eyes cannot capture any infrared laser radiation and reflection. In avoid to avoid thermal energy hurt to human eyes or retina, please wear correct laser safety goggles and avoid eye exposure to beam aperture until achieving safe and free use perfectly.
