685nm 5mW to 100mW Red Line Laser Modules
Industrial stabilized 685nm red line laser modules applies import 685nm red laser diode, thermal emitting system, qualified optic lens, assuring intense and high brightness red laser light emission through beam aperture. Under operation with constant electric power source, and proper mounting onto industrial machine or device, it makes sure of the most convenient, easy reaching and good direction red line measurement for prominent colleges, labs and institutes.
- Buy 3 for $147.99 each and save 1%
- Buy 5 for $145.99 each and save 3%
- Buy 10 for $143.99 each and save 4%
Employing durable and ultra compact designed anodized aluminum alloy housing tube, 685nm red line laser modules within 5mW to 100mW allows the most convenient installation, no track, noncontact and no manual labor force input line generation for multiple industrial and high tech precise line alignment fields. Easy adjustment of both red line fineness and red line projecting direction ensures n mistake and low cost, and high efficiency measurement constantly.
Key features:
685nm red laser modules within 5mW to 100mW assure highly visible and intense red laser beam emission at several miles, and fulfill tasks requiring of moderate accuracy and formal brightness occasions.
5V, 9V 1000mA AC/DC adapter leaves even larger space for laser module tube cooling down, keeps work with continuous red laser light and red reference line projection. No effect of overheating and over current impact as well.
Ultra compact 16mm and 26mm diameter metal housing tube gets superior nice thermal conductivity, wide range operating temperature stabilization, and stable red line alignment under moving or shocking in use.
APC, ACC driving circuit board protects red laser line generator with stable and reliable performance, reduced possibility of tube burning out or damage, long lifetime of more than 8,000 hours.
Easy screw of adjustable focus optic lens enables high quality red laser light concentration, and increasing accuracy and brightness red line alignment in constant use.
Technical data:
| Item | Red Line Laser Modules |
| Wavelength (nm) | 685nm |
| Output power (mW) | 5mW, 10mW, 20mW, 30mW, 50mW, 80mW, 100mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIa, IIIB |
| Beam thickness at aperture (mm) | <2mm; At 2m distance: <2mm |
| Beam divergence (mrad) | 5mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 685nm red line laser module and 1 ea AC/DC adapter
Applications: industrial precise line alignment, drilling system, textile processing, spectrum analysis, laser light show, measurement etc
Note: For operation of 685nm red lasers up to 50mW to 100mW, do be careful of powerful red laser radiation and thermal energy hurt to human eyes or retina. Please remember to wear correct laser safety goggles and avoid eye exposure to beam aperture so as to make easy and free line alignment.
