5mW to 100mW 658nm Red Laser Line Generators
Direct diode emission 658nm red laser line generator makes advanced use of import 658nm red laser diode, qualified optic lens and electric driving circuit board, configuring with durable anodized aluminum alloy housing tube. It gets superior strong industrial stabilization, good laser beam stability, and highly clear red line measuring solution for prominent colleges, labs and institutes.
- Buy 3 for $87.99 each and save 2%
- Buy 5 for $85.99 each and save 4%
- Buy 10 for $83.99 each and save 7%
Professional industrial line aligning tool of 658nm red laser line generators applies qualified glass coated lens or Powell lens within 10 to 110 degree, assures high quality red laser source emission and high linear quality red line with various line lengths and finenesses. After easy use of external electric power source and freely adjusted laser beam focus, 658nm red laser module makes sure of focused red laser light and increasing fineness red line alignment constantly.
Key features:
Import 658nm red laser diodes within 5mW to 100mW assures highly visible red laser beam emission at several miles far away, and highly clear red line alignment within the maximum distance of 25 meters and formal lighting.
AC/DC adapter with 5V, 9V power source supports 658nm red laser module with constant red reference line projection, and high beam stability after 8 to 10 hours use. No appearances of light decay or blur in continuous use.
Wide fan angles of 10 to 110°glass coated lens or separate crystal lens made 658nm red laser modules project high quality Gaussian or Non Gaussian distribution red laser beam, generate high fineness red line with various line lengths for multiple application fields.
Easy screw of adjustable focus optic lens enables high speed red laser light concentration, and efficient conversion of high fineness and high brightness red line alignment in distance.
APC, ACC driving circuit board makes intelligent feedback control of output power and electric current supply, and up to 85% laser beam stability and long lifetime of up to 8,000 hours.
CW or pulsing laser selectable
Technical data:
| Item | Red Laser Line Generators |
| Wavelength (nm) | 658nm |
| Output power (mW) | 5mW, 10mW, 20mW, 30mW, 50mW, 80mW, 100mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIa, IIIB |
| Beam thickness at aperture (mm) | <2mm; At 2m distance: <2mm |
| Beam divergence (mrad) | 5mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 658nm red laser line generator and 1 ea AC/DC adapter
Applications: drilling system, lumber machine, laser cutting machine, laser medical therapy, and lab experiment etc
Note: The use of high power 658nm red laser module up to 50mW to 100mW generates powerful red laser light and thermal energy of beam aperture. Please take laser safety measure and wear correct laser safety goggles so as to assure secured and fine red line alignment constantly.
