5mW to 100mW 655nm Red Line Laser Modules
Industrial stabilized 655nm red line laser module employs an import 655nm red laser diode, qualified optic lens, APC, ACC driving circuit board, always assuring superior nice thermal emitting and highly stable red laser light and red reference line projection from beam aperture. After easy use of an external electric power source and freely adjusted red line fineness, it makes high precision, low cost and quick response line alignment constantly.
- Buy 3 for $97.99 each and save 2%
- Buy 5 for $95.99 each and save 4%
- Buy 10 for $93.99 each and save 6%
Available with qualified glass coated lens or Powell lens within 10 to 93 degree fan angles, after strict laser beam stability and aging preventing test up to 24 hours, the genuine use of 658nm red line laser module projects high quality Gaussian or non Gaussian distribution red laser light of beam aperture. After easy screw of adjustable focus lens, laser line generator gets freely adjusted line fineness, and increasing accuracy red line measurement for prominent labs, institutes and colleges.
Key features:
5mW to 100mW 655nm red line laser modules with metal heat sink cooling system inside durable anodized aluminum alloy housing tube assure excellent thermal emitting, and highly stable red line alignment for both long distance and long lasting use.
5V, 9V 1000mA AC/DC adapter provides constant electric power source for laser line generator, assuring continuous red line projection and no effect of overheating and over current impact.
Adjustable focus optic lens enables high speed red laser light concentration, converts into increasing brightness and fineness red line emission.
16mm and 26mm ultra compact design tube assures convenient installation, easy line projection, and noncontact red line measurement.
APC, ACC driving circuit board makes intelligent feedback control of output power and electric current supply, and up to 85% laser beam stability after constant work within 8 to 10 hours.
CW or pulsing laser selectable
Technical data:
| Item | Red Line Laser Modules |
| Wavelength (nm) | 655nm |
| Output power (mW) | 5mW, 10mW, 20mW, 30mW, 50mW, 80mW, 100mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIa, IIIB |
| Beam thickness at aperture (mm) | <2mm; At 2m distance: <2mm |
| Beam divergence (mrad) | 5mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 655nm red line laser module and 1 ea AC/DC adapter
Applications: industrial line alignment, laser collimation, laser medical therapy, scientific research, optical instrument
Note: The use of high power 655nm red laser up to 50mW to 100mW generates powerful red laser radiation and reflection. In order to avoid thermal energy hurt to human eyes, please wear correct laser safety goggles so as to achieve easy and safe line alignment constantly.
