450nm 5mW to 100mW Blue Cross Line Laser Modules
Industrial stabilized 450nm 5mW to 100mW blue cross line laser modules adopt import 450nm blue laser diode, qualified glass coated lens and APC, ACC driving circuit board, project high stability and high transmittance blue laser light of beam aperture. After easy use of external electric power source and mounting onto industrial device, it brings users high speed, good direction and low production cost blue cross line alignment in distance.
- Buy 3 for $127.99 each and save 2%
- Buy 5 for $125.99 each and save 3%
- Buy 10 for $123.99 each and save 5%
Direct diode emission 450nm blue cross line laser module applies the best quality glass coated lens with different fan angles, equipping with up to 24 hours aging preventing test and special designed glass window, it achieves high intensity blue laser light, and high linear quality two perpendicular blue lines. After correct use of fan angle and easy screw of adjustable focus optic lens, blue laser makes high accuracy and fineness cross line alignment for industrial and high tech measurements.
Key features:
Wide output power 5mW to 100mW 450nm blue cross laser with metal heat sink and APC, ACC driving circuit board assures increasing laser beam stability, long lasting cross line alignment and no tube burning out or damage.
Qualified glass coated lens with 10, 15, 110 degree fan angles generates different dimension blue cross line lengths, applying for multiple precise cross line measurements.
5V, 9V 1000mA AC/DC adapter connected blue laser enables constant blue laser beam and blue cross line alignment, freely installed distance of 3 meters, no track and no barrier use.
Adjustable focus optic lens enables immediate blue laser light concentration, converts into high brightness and high fineness cross line alignment in distance.
CW or pulsing laser selectable
Technical data:
| Item | Blue Cross Line Laser Module |
| Wavelength (nm) | 450nm |
| Output power (mW) | 5mW, 10mW, 20mW, 30mW, 50mW, 80mW, 100mW |
| Available Fan Angle(degrees) | 10°, 15°, 110° |
| Laser Class | IIIa, IIIB |
| Beam thickness at aperture (mm) | <2.5mm |
| Beam divergence (mrad) | 3mrad |
| Beam mode (before optics) | TEM |
| Focus adjustable? | Yes |
| TTL Modulation | No |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L71mm; D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 450nm blue cross line laser module and 1 ea AC/DC adapter
Application: laser show, laser displaying, laser communication, scientific research and lab experiment
Note: For operation of high power 450nm blue laser up to 50mW to 100mW generates powerful red laser radiation and reflection, which might cause thermal energy hurt to human eyes or retina. Do remember to wear laser safety goggles and avoid eye exposure to beam aperture so as to make easy and free measurement.
