447nm 5mW to 100mW Adjusted Fineness Blue Line Laser Modules
High brightness blue laser beam emitting tool of 447nm blue line laser modules make good use of import 447nm blue laser diode, qualified optic lens with wide fan angles, providing users the best quality and the most intense blue laser light source emission. After easy mounting and adjusting of both line fineness and line projecting direction, it provides users high level of accuracy and high fineness blue line measurement for both high tech and industrial line aligning fields.
- Buy 3 for $127.99 each and save 2%
- Buy 5 for $125.99 each and save 3%
- Buy 10 for $123.99 each and save 5%
High stability and low production cost blue line aligning solution with direct diode emission 447nm blue line laser modules.
Import 447nm blue laser diodes within 5mW to 100mW assures highly visible blue laser beam emission, and highly clear blue reference line projection for multiple application fields.
AC/DC adapter with 5V, 9V operating voltage supports 447nm blue line laser module with continuous blue line indication, no affect by increasing temperature and electric current impact.
Ultra compact and anodized aluminum alloy housing tube with 16mm and 26mm diameter tube leaves enough space for metal heat sink cooling system. Blue laser line generator applies for wide operating temperature and harsh occasions.
Wide fan angles of 10° to 110°glass coated lens and Powell lens assures high linear quality and high fineness blue line indication, no light decay or dim in continuous use.
Easy screw of adjustable focus optic lens made 447nm blue line laser modules assures intense blue laser light concentration, and increasing accuracy and brightness blue line measurement for high precision aligning use.
Technical data:
| Item | Blue Line Laser Module |
| Wavelength (nm) | 447nm |
| Output power (mW) | 5mW, 10mW, 20mW, 30mW, 50mW, 80mW, 100mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIa, IIIB |
| Beam thickness at aperture (mm) | <2.5mm; At 2m distance: <2.5mm |
| Beam divergence (mrad) | 3.0mrad |
| Beam mode (before optics) | TEM |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 447nm blue line laser module and 1 ea AC/DC adapter
Applications: laser show, laser displaying, laser medical therapy device, laser communication, scientific research etc
Note: high power 447nm blue line laser up to 50mW to 100mW generates intense blue laser radiation and thermal energy. Do remember to avoid eye exposure to beam aperture and wear correct laser safety goggles so as to assure secured and free line alignment constantly.
